BODY
Cast Iron, ASTM Al26 Class B IS 210 FG 260 Ductile Iron, ASTM A 395 (60-40-18) WCB (CS) ASTM A 216 Stainless Steel (CF8M/CF8) ASTM A 351M/351

DISC
Cast Iron, ASTM Al26 Class B IS 210 FG 260 Ductile Iron, ASTM A 395 (60-40-18) WCB (CS) ASTM A 216 Stainless Steel (CF8M/CF8) ASTM A 351M/351 Alluminium Bronze, Duplex , Super Duplex *DISC also available with Rubber Lining in EBBONITE/ EPDM/NBR/NYLON/HYPLON (with Gurranted Spark Test Pass)

SEAT
EPDM / White EPDM (FOOD GRADE) BUNA-N / White - BUNA N (Food Garde) (NITRILE - NBR) Viton, Hyplon, Butyle, Silicon, Neoprene, Natural Rubber

STEM
Stainless Steel ASTM A 479 TYPE 410 Stainless Steel ASTM A 276 TYPE 316 Stainless Steel ASTM A 276 TYPE 304 Duplex, Super Duplex, Monel, Bronze

STEM BUSHING : PTFE, ACETAL

OIL SEAL (Stem Seal) : EPDM

WASHER : SS304

RETAINING CIRCLIP : SPRING STEEL

Note: All Body and Disc are IC Cast from 1.5"(DN40) To 24" (DN600) Available. any other Special Material are also work on request for Body / Disc / Stem / Seat.

Design & Manufacturing Standards
API 609 / BS EN - 593 / IS13095 / ASME B16.51S0 7005

Testing Standard
API 598 / API6D / BSEN 12266-1

Valve face to face Dimension
Category A API 609 / IS13095 / ENS93 / ISOS752Tab5

TOP Flange Drilling
ISO 5211

Flang Standard
DIN EN 1092-PN6, PN10, Class 150, Bs10 Tub DoE, 1S6392, Tab 11/17, JIS 5K/10K
